Flat shading is the simplest shading model which calculates the illumination at a single point for each polygon (or polygon vertices in OpenGL) which means that it the color is the same for all points of each polygon
Advantages
- Fast, a single computation per polygon (or one per polygon vertex in OpenGL)
Disadvantages
- Inaccurate
- Discontinuities at polygon boundaries
Implementation
GLSL has the keyword flat
to skip interpolation
// vertex shader
flat out vec4 polygon_color;
void main() {
// ...
polygon_color = vec4(ambient + diffuse + specular, 1.0);
}
// fragment shader
flat in vec4 polygon_color;
out vec4 color;
void main () {
color = polygon_color;
}
References
- Illumination-based Shading. Retrieved 9 June 2016, from http://www.di.ubi.pt/~agomes/cg/teoricas/07e-shading.pdf
- TU Wien Rendering #4, from https://www.youtube.com/watch?v=Gm7szS1hQxs
